Multi-technology range
Smart Metering
Multi Inputs & Outputs

LoRaWAN / Sigfox

IP66/67 (IP68 on request)

> 10 years

Click to enlarge

Multi-technology Radio Transmitter / Multi Inputs & Outputs

The ACW-MIO allows connection, depending on the version, of 1 or 2 analog sensors (4/20mA or 0/10V) as well as one or two digital inputs (configurable for state change detection or pulse counting). Battery-powered, this product features a controlled 5V, 12V or 24V DC power supply output to power the external sensor just before performing the measurement.

The ACW-MIO (Multi-I/O) is available in 4 versions :

ACW-MIO-1M8: 2 inputs, 1 female M8 4-pin connector
ACW-MIO-2M8: 4 inputs, 2 female M8 4-pin connectors
ACW-MIO-C0: 2 inputs, cable gland, cable not supplied
ACW-MIO-C1: 2 inputs, cable gland with cable, pre-assembled, 1 m length

These products are available in LoRaWAN / Sigfox (/LS8), and there is also a cellular version (/CEL) with data transmission via the NB-IoT network or via the LTE-M (Cat-M1) network.

Description

MONITORING	1 sensor input 4/20mA or 0–10V (reconfigurable as a digital input) 1 digital input (configurable for state change or pulse counting) 1 controlled power supply output for external sensor 2M8 version: these inputs/outputs are doubled on this version
BATTERY LIFE	Up to 10 years of battery life*
BATTERY	Replaceable batteries
ENCLOSURE	IP66/67 (IP68 on request)
CONFIGURATION	Downlink Bluetooth (BLE 4.2)
