Modbus RTU Digital Analogue radio Modem

Input-output ports – Mirror / Modbus modes

The ARM-Dxxxx facilitates the transmission of Modbus information. With a serial connection RS232 or RS485, it interfaces with industrial automatons. The radio modem transfers up to 10 digital 0-30V inputs + 10 outputs, 4 analog inputs + 4 analog outputs from one PLC to another in P2P radio. Sigfox or LoRaWAN versions are also available to send information from an isolated Modbus PLC to IoT clouds.

Its configuration is configurable from the tools of the ATIM suite.

Compatible with the computer and mobile versions of the IoT web platform, data visualization, remote setting of the sensor and the configuration of alerts according to predefined thresholds are made possible in a few clicks.

Installation and start-up takes less than 10 minutes: Plug & Play.

Description

SURVEILLANCE	2 entrées digitales 0-30V 2 sorties digitales 0-30V
ANTENNE	Connecteur SMA tout types d’antennes
ALIMENTATION	10-30 Vdc
CONFIGURATIONS	USB Commandes AT
MODES	Miroir Modbus RTU LPWAN gateway
OPTIONS	+ 4 entrées/sorties digitales 0-30V + 4 entrées/sorties analogiques 4-20mA + 8 entrées digitales 0-30V & + 8 sorties digitales 0-30V
PLUG & PLAY	Installation en moins de 10 minutes

ARM-Dxxxx – FR

Additional information

Technology	LoRaWAN, M2M, Sigfox
References	ARM-D88-EXT, ARM/868-D2200, ARM/868-D2201, ARM/868-D2202, ARM/868-D2203, ARM/868-D2204, ARM/868-D2210, ARM/868-D2211, ARM/868-D2212, ARM/868-D2221, ARM/LW8-Dxxxx, ARM/SF8-Dxxxx

Documentation

SURVEILLANCE	2 entrées digitales 0-30V 2 sorties digitales 0-30V
ANTENNE	Connecteur SMA tout types d’antennes
ALIMENTATION	10-30 Vdc
CONFIGURATIONS	USB Commandes AT
MODES	Miroir Modbus RTU LPWAN gateway
OPTIONS	+ 4 entrées/sorties digitales 0-30V + 4 entrées/sorties analogiques 4-20mA + 8 entrées digitales 0-30V & + 8 sorties digitales 0-30V
PLUG & PLAY	Installation en moins de 10 minutes

ARM-Dxxxx – FR
